CRANKCASE FOR MV AGUSTA F4 R 2013

CRANKSHAFT

(1) 8A00B7101

BASE COVER

(2) 8B00B2807

VALVE, OIL, CRANKCASE BOTTOM

(3) 8D0092465

BLOW-BY COVER LABIRINT

(4) 8000B4019

GASKET, BLOW-BY COVER

(5) 8B00B2684

SCREW, M8X1,25 DA CARCA?A

(6) 8A00B2684

SCREW, M8X1,25

(6) 8A00B2684

SCREW, M8X1,25

(7) 8J00B2681

SCREW M6X1 L35 CH8

(7) 8J00B2681

SCREW M6X1 L35 CH8

(8) 8G00B2681

SCREW M6X1 CH8

(9) 800007719

PIN D10-D7

(10) 8A0051549

REFERENCE PIN D6.2-D8-SP.1

(11) 800086119

BUSH, CRANKCASE, 27X12MM

(12) 800087300

BEARING

(13) 800081422

BEARING

(14) 800086737

WASHER, FIXACAO DO ROLAMENTO

(15) 8B00B2695

SCREW, M6X1 CH4

(16) 8C0019590

PIN, CLUTCH COVER, 15X5MM

(17) 8000B2746

CILINDIRCAL PLUG DIN 908-M16X1

(18) 800089426

WASHER D16

(19) 8000B2532

BEARING, PRIMARY AXLE

(20) 8C00B2695

SCREW, M6X1 DO SUPORTE DO ROL

(21) 8000B2063

CHANGE GEAR

(22) 8000B2560

SUPPORT, FIX, PRIMARY AXLE BEA

(23) 8000A2170

STUD BOLT, EXHAUST, CYLINDER H

(24) 8000A2171

STUD BOLT, INTAKE, CYLINDER HE

(25) 8000A1087

BEARING, SECONDARY AXLE, RNU41

(26) 800081412

CRANKCASE PLUG

(27) 800081317

ROD BEARING, 1-3-4-6 A

(27) 800081317

ROD BEARING, 1-3-4-6 A

(27) 800081317

ROD BEARING, 1-3-4-6 A

(27) 800081317

ROD BEARING, 1-3-4-6 A

(27) 8A0081317

ROD BEARING, 1-3-4-6 B

(27) 8A0081317

ROD BEARING, 1-3-4-6 B

(27) 8A0081317

ROD BEARING, 1-3-4-6 B

(27) 8A0081317

ROD BEARING, 1-3-4-6 B

(27) 8B0081317

ROD BEARING, 1-3-4-6 C

(27) 8B0081317

ROD BEARING, 1-3-4-6 C

(27) 8B0081317

ROD BEARING, 1-3-4-6 C

(27) 8B0081317

ROD BEARING, 1-3-4-6 C

(28) 800081316

RED CRANKSHAFT BEARING

(28) 800081316

RED CRANKSHAFT BEARING

(28) 8A0081316

BLUE ROD BEARING, 2-5 B

(28) 8A0081316

BLUE ROD BEARING, 2-5 B

(28) 8B0081316

YELLOW ROD BEARING, 2-5 C

(28) 8B0081316

YELLOW ROD BEARING, 2-5 C

(29) 8A0031106

WASHER, DE BORRACHA ORING 20

(30) 800035728

COVER, MINOR, SEALING, CRANKCA

(31) 8000B3014

SCREW, ESPECIAL FIXA?AO DO SU

(32) 80B0B2004

COVER, GENERATOR

(33) 800051549

PIN D8-D6

(34) 8000B2066

GASKET, GENERATOR COVER

(35) 8G00B2681

SCREW M6X1 CH8

(36) 8A00B3288

CLUTCH COVER

(37) 8000B7751

OIL CHECK WINDOWS

(38) 800080691

CLUTCH COVER GASKET

(39) 8E00B2681

SCREW M6X1-CH8-L20

(40) 80B0B3436

COVER INSPECTION, CRANKSHAFT

(41) 800094626

GASKET, RPM GEAR COVER, F4

(42) 8E00B2681

SCREW M6X1-CH8-L20

(43) 80B0B3291

OIL PAN

(44) 8000B3455

GASKET, CARTER COVER

(45) 800007719

PIN D10-D7

(46) 8H00B2681

SCREW M6X1 CH8 RP

(47) 80B0B5295

OIL FILTER COVER

(48) 8000B3457

ORING, OIL FILTER COVER

(49) 8C00B2681

SCREW, TEF M6X1 CH8 L14

(50) 8000A1792

CLAMP, SPECIAL

(51) 80B0B3092

FLANGE OIL PIPES SUPPORT

(52) 8A0023111

OR2106 T1

(53) 8A00A0819

GROMMET D15,08

(54) 8E00B2681

SCREW M6X1-CH8-L20

(55) 8000B7711

8000B7711

(56) 8000B8240

SCREW ECU

(57) 62N015682

WASHER, 28X22,3X1MM

(58) 800096747

PLUG, OIL, M22X1,5MM

(59) 80B0A5147

OIL PLUG

(60) 8A0023120

RING, RUBBER, OIL COVER, 26,65

(61) 8B0023109

RING, RUBBER, CRANKCASE, 12,42

(62) 8000B5278

PISTON OIL NOZZLE

(62) 8000B5278

PISTON OIL NOZZLE

(63) 800023106

OR106 T1,78-D6,75

(63) 800023106

OR106 T1,78-D6,75

(64) 8000B7741

BRACKET, HOSE EXHAUST VALVE

(65) 800094896

CAP, RUBBER, SCREW, 2

	Part number	Description	Qty
# 1	8A00B7101	BASE COVER	2 850,94 €(2 441,20 £)
# 2	8B00B2807	VALVE, OIL, CRANKCASE BOTTOM	6,73 €(5,76 £)
# 3	8D0092465	BLOW-BY COVER LABIRINT	116,42 €(99,69 £)
# 4	8000B4019	GASKET, BLOW-BY COVER	9,31 €(7,97 £)
# 5	8B00B2684	SCREW, M8X1, 25 DA CARCA?A	7,20 €(6,17 £)
# 6	8A00B2684	SCREW, M8X1, 25	5,88 €(5,03 £)
# 7	8J00B2681	SCREW M6X1 L35 CH8	1,98 €(1,70 £)
# 8	8G00B2681	SCREW M6X1 CH8	1,19 €(1,02 £)
# 9	800007719	PIN D10-D7	4,96 €(4,25 £)
# 10	8A0051549	REFERENCE PIN D6.2-D8-SP.1	3,90 €(3,34 £)
# 11	800086119	BUSH, CRANKCASE, 27X12MM	9,90 €(8,48 £)
# 12	800087300	BEARING	12,61 €(10,80 £)
# 13	800081422	BEARING	59,93 €(51,32 £)
# 14	800086737	WASHER, FIXACAO DO ROLAMENTO	10,24 €(8,77 £)
# 15	8B00B2695	SCREW, M6X1 CH4	1,19 €(1,02 £)
# 16	8C0019590	PIN, CLUTCH COVER, 15X5MM	1,39 €(1,19 £)
# 17	8000B2746	CILINDIRCAL PLUG DIN 908-M16X1	4,82 €(4,13 £)
# 18	800089426	WASHER D16	1,52 €(1,30 £)
# 19	8000B2532	BEARING, PRIMARY AXLE	307,16 €(263,01 £)
# 20	8C00B2695	SCREW, M6X1 DO SUPORTE DO ROL	3,30 €(2,83 £)
# 21	8000B2063	CHANGE GEAR	42,58 €(36,46 £)
# 22	8000B2560	SUPPORT, FIX, PRIMARY AXLE BEA	4,69 €(4,02 £)
# 23	8000A2170	STUD BOLT, EXHAUST, CYLINDER H	25,02 €(21,42 £)
# 24	8000A2171	STUD BOLT, INTAKE, CYLINDER HE	24,42 €(20,91 £)
# 25	8000A1087	BEARING, SECONDARY AXLE, RNU41	174,24 €(149,20 £)
# 26	800081412	CRANKCASE PLUG	18,74 €(16,05 £)
# 27	800081317	ROD BEARING, 1-3-4-6 A	25,61 €(21,93 £)
# 27	8A0081317	ROD BEARING, 1-3-4-6 B	25,61 €(21,93 £)
# 27	8B0081317	ROD BEARING, 1-3-4-6 C	25,61 €(21,93 £)
# 28	800081316	RED CRANKSHAFT BEARING	25,61 €(21,93 £)
# 28	8A0081316	BLUE ROD BEARING, 2-5 B	25,61 €(21,93 £)
# 28	8B0081316	YELLOW ROD BEARING, 2-5 C	25,61 €(21,93 £)
# 29	8A0031106	WASHER, DE BORRACHA ORING 20	2,11 €(1,81 £)
# 30	800035728	COVER, MINOR, SEALING, CRANKCA	7,79 €(6,67 £)
# 31	8000B3014	SCREW, ESPECIAL FIXA?AO DO SU	7,07 €(6,05 £)
# 32	80B0B2004	COVER, GENERATOR	83,76 €(71,72 £)
# 33	800051549	PIN D8-D6	3,77 €(3,23 £)
# 34	8000B2066	GASKET, GENERATOR COVER	9,18 €(7,86 £)
# 35	8G00B2681	SCREW M6X1 CH8	1,19 €(1,02 £)
# 36	8A00B3288	CLUTCH COVER	225,40 €(193,01 £)
# 37	8000B7751	OIL CHECK WINDOWS	22,78 €(19,51 £)
# 38	800080691	CLUTCH COVER GASKET	Contact	0,00 €(0,00 £)
# 39	8E00B2681	SCREW M6X1-CH8-L20	1,19 €(1,02 £)
# 40	80B0B3436	COVER INSPECTION, CRANKSHAFT	96,62 €(82,73 £)
# 41	800094626	GASKET, RPM GEAR COVER, F4	8,92 €(7,64 £)
# 42	8E00B2681	SCREW M6X1-CH8-L20	1,19 €(1,02 £)
# 43	80B0B3291	OIL PAN	237,34 €(203,23 £)
# 44	8000B3455	GASKET, CARTER COVER	29,11 €(24,93 £)
# 45	800007719	PIN D10-D7	4,96 €(4,25 £)
# 46	8H00B2681	SCREW M6X1 CH8 RP	1,19 €(1,02 £)
# 47	80B0B5295	OIL FILTER COVER	63,36 €(54,25 £)
# 48	8000B3457	ORING, OIL FILTER COVER	3,77 €(3,23 £)
# 49	8C00B2681	SCREW, TEF M6X1 CH8 L14	1,06 €(0,91 £)
# 50	8000A1792	CLAMP, SPECIAL	2,71 €(2,32 £)
# 51	80B0B3092	FLANGE OIL PIPES SUPPORT	57,89 €(49,57 £)
# 52	8A0023111	OR2106 T1	3,50 €(3,00 £)
# 53	8A00A0819	GROMMET D15, 08	2,45 €(2,10 £)
# 54	8E00B2681	SCREW M6X1-CH8-L20	1,19 €(1,02 £)
# 55	8000B7711	8000B7711	Contact	0,00 €(0,00 £)
# 56	8000B8240	SCREW ECU	11,69 €(10,01 £)
# 57	62N015682	WASHER, 28X22, 3X1MM	1,98 €(1,70 £)
# 58	800096747	PLUG, OIL, M22X1, 5MM	23,70 €(20,29 £)
# 59	80B0A5147	OIL PLUG	50,23 €(43,01 £)
# 60	8A0023120	RING, RUBBER, OIL COVER, 26, 65	4,82 €(4,13 £)
# 61	8B0023109	RING, RUBBER, CRANKCASE, 12, 42	1,19 €(1,02 £)
# 62	8000B5278	PISTON OIL NOZZLE	43,56 €(37,30 £)
# 63	800023106	OR106 T1, 78-D6, 75	Contact	0,00 €(0,00 £)
# 64	8000B7741	BRACKET, HOSE EXHAUST VALVE	6,94 €(5,94 £)
# 65	800094896	CAP, RUBBER, SCREW, 2	2,84 €(2,43 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from MV Agusta. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKCASE of your MV Agusta F4 R of 2013. Let us know if you have any questions.
