CYLINDER & PISTON

CYLINDER HEAD FOR MV AGUSTA F4 TAMBURINI 2004

TIMING SYSTEM

(1) 8A00A3718

HEAD

(2) 800069769

CONICAL PLUG EI M14X1

(3) 8A0081228

NOT AVAILABLE GUIDA VALVOLA MAGG. 0.025

(3) 8B0081228

VALVE GUIDE 0.050 MM

(4) 8000B2768

STUD BOLT

(5) 800051549

PIN D8-D6

(6) 800085071

SCREW M6X35

(7) 800065814

INTAKE AND EXHAUST GASKET

(8) 800092428

INTAKE VALVE D29 JAP

(9) 800092429

VALVOLA SCARICO D25 JAP ARTICOLO IN ESAURIMENTO

(10) 8000A1940

VALVE OUTER SPRING

(11) 8000A1941

VALVE INNER SPRING

(12) 8000A5496

VALVE SEAT

(13) 8000A4840

VALVE SEAT

(14) 800092433

COTTER VALVE 15JAP

(15) 800087752

ORING, LARGE

(16) 8A0092447

COVER CYLINDER HEAD

(17) 800087756

RC GASKET

(18) 8000B7740

GASKET SPARK PLUG

(19) 800087779

SCREW

(20) 8A0025082

O RING

(21) 800081547

NUT, ESPECIAL DO CABE?OTE 1

(22) 800069156

WASHER, 18X10,5X2 FLAT, BLACK

(23) 800098670

EXTERNAL VALVE SPRING

(24) 800098671

INTERNAL VALVE SPRING

	Part number	Description	Qty
# 1	8A00A3718	HEAD	Contact	0,00 €(0,00 £)
# 2	800069769	CONICAL PLUG EI M14X1	4,09 €(3,50 £)
# 3	8B0081228	VALVE GUIDE 0.050 MM	Contact	0,00 €(0,00 £)
# 3	8A0081228	NOT AVAILABLE GUIDA VALVOLA MAGG. 0.025	Contact	0,00 €(0,00 £)
# 4	8000B2768	STUD BOLT	11,88 €(10,17 £)
# 5	800051549	PIN D8-D6	3,77 €(3,23 £)
# 6	800085071	SCREW M6X35	3,17 €(2,71 £)
# 7	800065814	INTAKE AND EXHAUST GASKET	8,39 €(7,18 £)
# 8	800092428	INTAKE VALVE D29 JAP	Contact	0,00 €(0,00 £)
# 9	800092429	VALVOLA SCARICO D25 JAP ARTICOLO IN ESAURIMENTO	Contact	0,00 €(0,00 £)
# 10	8000A1940	VALVE OUTER SPRING	Contact	0,00 €(0,00 £)
# 11	8000A1941	VALVE INNER SPRING	Contact	0,00 €(0,00 £)
# 12	8000A5496	VALVE SEAT	Contact	0,00 €(0,00 £)
# 13	8000A4840	VALVE SEAT	Contact	0,00 €(0,00 £)
# 14	800092433	COTTER VALVE 15JAP	3,77 €(3,23 £)
# 15	800087752	ORING, LARGE	2,24 €(1,92 £)
# 16	8A0092447	COVER CYLINDER HEAD	Contact	0,00 €(0,00 £)
# 17	800087756	RC GASKET	46,73 €(40,01 £)
# 18	8000B7740	GASKET SPARK PLUG	8,92 €(7,64 £)
# 19	800087779	SCREW	Contact	0,00 €(0,00 £)
# 20	8A0025082	O RING	2,51 €(2,15 £)
# 21	800081547	NUT, ESPECIAL DO CABE?OTE 1	19,08 €(16,34 £)
# 22	800069156	WASHER, 18X10, 5X2 FLAT, BLACK	2,11 €(1,81 £)
# 23	800098670	EXTERNAL VALVE SPRING	17,89 €(15,32 £)
# 24	800098671	INTERNAL VALVE SPRING	11,95 €(10,23 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from MV Agusta. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER HEAD of your MV Agusta F4 TAMBURINI of 2004. Let us know if you have any questions.
